Automatic Hematology Analyzer Medconn DX-100

Medconn DX-100 is an expert-level, high-throughput automated hematology system engineered for medium to large-scale clinical laboratories with demanding workflows. Utilizing advanced semiconductor laser flow cytometry (FCM) and nucleic acid fluorescent staining technologies, the DX-100 delivers exceptional analytical precision, deep cellular differentiation, and comprehensive clinical screening capabilities.

Key Advantages:

• High Throughput: Delivers up to 100 tests per hour (CBC+DIFF mode) and 83 tests per hour with reticulocyte testing (CBC+DIFF+RET).

• Multi-Channel Fluorescence Analysis: Features dedicated optical channels for Reticulocytes (RET), Immature Platelet Fraction (IPF), Fluorescent Platelets (F-PLT), and White Blood Cell Pathological Analysis (WPC).

• Advanced Diagnostic Parameters: Precise detection of Nucleated Red Blood Cells (NRBC), Immature Granulocytes (IG), Atypical Lymphocytes (Aty-LYM), and malaria screening indicators.

• Versatile Sample Management: Supports venous blood, capillary blood, pre-diluted samples, and biological body fluids.

• Scalable Modular Design: Built for flexibility, allowing easy integration into automated workcells to match long-term laboratory expansion.

Technical Specifications:

• Assay Principles:

  • WBC, DIFF, RET, F-PLT, WPC: Flow Cytometry & Fluorescent Staining (FCM)

  • RBC, PLT: Sheath Impedance Method

  • HGB: Colorimetric Method

• Throughput:

  • CBC + DIFF: 100 T/H

  • CBC + DIFF + RET: 83 T/H

• Sample Volume: Whole blood mode: $\le$ 88 µL, Pre-dilution mode: $\le$ 70 µL, Body fluids: $\le$ 200 µL.

• Reportable Parameters (Blood): Over 37 reportable items (including full RET, IG, NRBC, IPF profiles) and 34 research parameters.

• Graphical Output: 2 histograms (RBC, PLT) and 5 scattergrams (WBC, DIFF, RET, F-PLT, WPC).

• Sample Loading Capacity: Auto-sampler holding 5 racks (10 tubes per rack) + manual mode for emergency STAT testing.

• Dimensions (W × D × H): 662 × 760 × 835 mm

• Weight: < 85 kg
